Wabash Combo Drop Deck Trailers
Sharpen Your Focus on the Bottom Line
With the Wabash Combo Drop Deck—one of the first combo platforms in the industry—you’ll experience rugged dependability and high payload capacity. Each configuration can be customized to meet your specific operational requirements.
Superior Design. Maximum Payload.
The main beam design comes with a limited lifetime warranty and provides a stronger web-to-flange attachment for long-life performance. Potential corrosion is eliminated between the flange and web by welding the high-tensile steel at all flange-web joints.
Lower Maintenance. Increased Uptime.
The interlocking four-nailer apitong and aluminum floor system connects with two grade-8 floor screws at each crossmember. This double-shear connection reduces racking and nailer damage. Radius edges on the “C” section siderail reduce strap wear, while the aluminum rub rail with recessed grooves protects conspicuity tape.
Better Visibility & Superior Corrosion Resistance
Enhanced lighting includes three stop/tail/turn lights and five dual-function side markers that double as turn signals. Every steel surface is shot-blasted before priming and painted with ultra high-zinc epoxy primer and automotive-grade urethane for corrosion resistance and higher resale value.
Combo Drop Deck Trailer Specifications
| Category | Details |
|---|---|
| General |
Length: 28′–53′ Width: 96″ and 102″ Upper Deck: 10′ or 11′ |
| Beam Rating |
554: 55,000 lb in 4′ / 60,000 lb in 10′ / 80,000 lb over lower deck 804: 80,000 lb in 4′ / 85,000 lb in 10′ / 94,000 lb over lower deck |
| Estimated Base Weight (48×102) |
554: 10,640 lb 804: 11,174 lb |
| Main Beam Design |
• Fully welded flange and web at all joints • High-strength 50,000 PSI steel web • Continuous automated welds • 130,000 PSI steel flanges • 24″ cross braces, 48″ knee braces • Lifetime main beam warranty |
| Front End Design |
• Fabricated aluminum front crossmember • Center-mount glad hands & 7-way access panel • ¼″ steel coupler plate (SAE J133 tested) |
| Rear End Design |
• Three stake pockets in rear plate • Horizontal bumper end caps • Rubber dock bumpers (3-bolt mounted) • DOT and Transport Canada compliant |
| Siderail Design |
• 6061-T6 extruded aluminum • Radius edges with rub rail groove • Stake pockets on 24″ centers • Large-diameter double pipe spools |
| Crossmembers & Floor |
• 80K high-tensile 4″ steel “I” beams on 12″ centers • Mylar gaskets between aluminum/steel • Aluminum & wood interlocking floor boards • 8 aluminum boards + apitong nailers (2 screws per crossmember) • Optional 5″ aluminum crossmembers |
| Undercarriage |
• Widespread K-bracing and gussets • Suspension support gussets • 121″ tandem axle setting • Large bearings and “P” spindle wheel ends |
| Electrical / Lights |
• Removable aluminum front plate access • Below-deck air and wire routing • LED lights (5 marker lights per side) • Dual-function lights (signal + marker) • ABS braking system |
| Finish & Prep |
• 100% shot-blasted before assembly • No chemical pretreatment required • Ultra high-zinc epoxy primer • Galvanic coating before assembly • Acrylic urethane paint system |
| Popular Options |
• Additional air/electric configurations • Extra aluminum components • Specialized coil & floor packages • Custom crossmember spacing • Beaver tail with level dampers • Factory bulkheads • Low deck option • Multiple axles, sliding/lift suspensions • Storage and freight securement options |
