Wabash Aluminum Drop Decks
Superior Main Beam. Lower Maintenance.
The two-piece, welded main beam design eliminates the need for mechanical fasteners by welding on the neutral axis—where bending stress is minimal. Unlike bolted designs, this beam has no fasteners that loosen over time, minimizing maintenance.
Less Weight. More Freight.
Floor crossmembers weld directly to the main beam, side rail, and floor to create a super-stiff structure—eliminating knee braces for a lighter trailer with less maintenance and increased payload efficiency.
Greater Flexibility. More Loaded Miles.
The Lock-Rite® multi-position tie-down system provides unmatched versatility—allowing loads to be secured either at the trailer’s center or along the outer siderails using straps or chains. Its patent-pending design maximizes load security and uptime.
Better Highway Visibility.
The enhanced lighting system includes three stop/tail/turn lamps and five dual-function side marker lights that also act as turn signals—improving highway safety and motorist awareness from every angle.
Aluminum Drop Deck Trailer Specifications
| Category | Details |
|---|---|
| General |
Length: 28′–53′ Width: 96″ and 102″ Upper Deck: 10′ or 11′ |
| Beam Rating | 524: 52,000 lb in 4′ / 55,000 lb in 10′ / 105,000 lb evenly distributed |
| 48′ Base Weight | 524: 9,203 lb / 4,174 kg |
| Main Beam Design |
• Welded, 2-piece, 6061 T6 extruded aluminum “T” cross sections • Beams welded along neutral axis • Floor sections welded to top flange of main beam • Top tee extrusion with integral Lock-Rite groove • Main beam camber cut in lower aluminum “T” section |
| Front End Design |
• High tensile steel neck for increased strength • Bright finish, fabricated aluminum front crossmember • Center mount glad hands and 7-way on removable access panel • ¼″ steel coupler plate welded to neck • Heavy-duty cross and aft bracing |
| Rear End Design |
• Closed section extruded rear light box • Three rear stake pockets with extruded pocket protector • Tubular bumper uprights with flanges for mounting accessories • Extruded grip surface on top of bumper tube • Rubber dock bumpers mounted vertically (3-bolt) • DOT and Transport Canada compliant bumper assemblies |
| Siderail Design |
• Extruded box section side rail with integral Lock-Rite groove • Radius edges to prevent strap damage • “LL” sliding winch track roadside, bolt-on design • Tumbled aluminum stake pockets on 24″ centers • Large diameter double pipe spools • Extruded aluminum rub rail with recessed groove |
| Crossmember & Floor System |
• 4-7/8″ aluminum C-channel crossmembers on 16″ centers • 1-1/4″ hollow core box design, extruded aluminum floor boards • Four apitong nailers (two outer, double center) • Crossmembers welded vertically to siderail and main beam, and horizontally to floor |
| Undercarriage |
• Lightweight formed suspension crossmembers at hangers and springs • Bolt-on lower steel C-channel and strut bracing • Air suspension with 5-year manufacturer warranty • 121″ tandem widespread axle setting • Large bearings, parallel “P” spindle wheel ends and axle alignment |
| Electrical / Lights |
• Air/electric accessible via removable front plate • Below deck routing • Enhanced visibility lighting system with recessed oval lights • LED lights (five marker lights per side, dual-function signals) • ABS (Anti-lock Brake System) |
| Popular Options |
• Additional air/electric configurations • Extra aluminum components • Alternate crossmember spacing • Corrosion prevention packages • Customized bumper filler plates • Disc brakes • Factory-installed bulkheads • Specialized floor packages • Multiple freight securement & storage options • Axle configurations, sliding/lift suspensions • Premium rear features |
