American-Made Durability. Best-in-Class Weight.
Wabash answered the need for a lighter-weight trailer without compromising the rugged performance you’ve come to expect from Wabash's original DuraPlate. Engineered cellular structures in DuraPlate Cell Core panels reduce weight without sacrificing strength or durability. Fleet-tested performance in high-cycle and high-use environments confirms: our standard dry vans with DuraPlate Cell Core Technology stand up to extreme loading and unloading, all while hauling more per load, saving fuel and increasing revenue per mile.
Wabash Dry Van Specifications
| Category | Details |
|---|---|
| General |
Dimensions: 53′ × 102-3/8″ × 13′6″ Front Interior Height: 110-1/4″ Rear Interior Height: 111-1/4″ Interior Width: 101″ GVWR: 68,000 lb / 30,845 kg GAWR: 20,000 lb / 9,072 kg ISO 9001:2015 Certified Facility |
| Nose / Coupler |
High-strength steel 3-3/8″ short-can coupler AAR-rated king pin with zinc anodes One-piece extruded aluminum header 3/16″ stainless steel lower nose rail |
| Sidewalls |
DuraPlate Cell Core composite panels (10-year limited warranty) Flat seam with overlapped top rail |
| Floor System |
20,000-lb dynamic load rating 1-3/8″ laminated oak boards (3 screws per board per crossmember) 4″ steel or aluminum crossmembers on 12″ centers Steel crossmembers over subframe and landing gear 8″ centers in rear 2′ Steel bolted attachment with grade-5 bolts |
| Rear Frame |
Hot-dipped galvanized 4-post rear impact guard Eyebrow and vertical light protection Rear header with integral gutter DuraPlate composite swing doors with 5 aluminum hinges per door TrustLock Plus® system, sill-mounted hardware, integral holdback |
| Suspension |
Mechanical or air suspension Parallel “P” spindle wheel ends Webb Lightweight Cast Hub & Vortex Drum with wear indicator Powder-coated steel wheels Low rolling-resistance tires Intercostal crossmember bracing over landing gear Galvanized steel landing-gear support & K-brace |
| Lights / Electrical |
All LED lighting EZ-7® modular 7-way with Wabash 3.0 sealed harness Upper ID / AUX stop-light system |
| Options |
Conventional DuraPlate sidewalls DuraPlate nose (riveted or bonded) Semi-insulated package Nose liner Flush-Mount Intermediate Logistics (16.6″ / 25″ centers) Floor kits in oak, aluminum, composite, or combination 24,000-lb & high-cycle load floors Multiple axle configurations Aerodynamic options Scuff liners (wood, steel, aluminum, plastic) Tire pressure / inflation systems Interior logistics (vertical / horizontal, bonded or riveted) Wide-base tires Clarience Road Ready MCU Phillips REAR-VU™ Backup Camera Overhead door: 110″ MaxClearance® w/ EZ-Adjust® system Extended 7-Year wheel-end warranty |
