The Heavy-duty Dry Van with Best-in-Class Weight
Wabash's dry van for high density loads features DuraPlate HD Cell Core Technology, our composite panel breakthrough that reduces trailer weight by 300 lbs. per 53’ trailer. This trailer is designed to support your toughest load requirements with exceptional durability and maximum payload capacity.
Wabash Duraplate HD Dry Van Specifications
| Category | Details |
|---|---|
| General |
Dimensions: 53′ × 102-3/8″ × 13′6″ Front Interior Height: 110-1/4″ Rear Interior Height: 111-1/4″ Interior Width: 101″ GVWR: 68,000 lb / 30,845 kg GAWR: 20,000 lb / 9,072 kg ISO 9001:2015 certified facility |
| Nose / Coupler |
3-3/8″ short-can coupler (high-strength steel) AAR-rated king pin with zinc anodes One-piece extruded aluminum header 3/16″ stainless steel lower nose rail |
| Sidewalls |
DuraPlate HD Cell Core composite panels (10-year limited warranty) Flat seam with overlapped top rail 22″ high aluminum base rail Double-shear rail connection |
| Floor System |
20,000 lb dynamic load rating 1-3/8″ laminated oak floorboards (3 screws per board per crossmember) 4″ steel or aluminum crossmembers on 12″ centers Steel crossmembers over subframe & landing gear 8″ centers in rear 2′ Bolted crossmembers with four 3/8″ grade-5 bolts |
| Roof System | Anti-snag roof bows mounted on 24″ centers |
| Rear Frame |
Galvanized 4-post rear impact guard (meets/exceeds DOT & Canadian offset regs) 5/16″ steel base plate + 1/2″ post protection Light eyebrow and vertical protection Integral gutter rear header DuraPlate composite swing doors (5 hinges per door) TrustLock Plus® system with sill-mounted hardware & integral door holdback |
| Suspension |
Mechanical or air suspension Parallel “P” spindle wheel ends Webb Cast Hub + Vortex Drum with wear indicator White powder-coated steel wheels Low rolling-resistance tires Intercostal crossmember bracing at landing gear Galvanized steel one-piece landing gear support & K-brace |
| Lights / Electrical |
All LED lighting EZ-7® modular 7-way with Wabash 3.0 sealed harness Upper ID / AUX stop-light system |
| Options |
Conventional DuraPlate sidewalls Bonded or riveted DuraPlate nose + liner Flush Mount Intermediate Logistics (16.6″ & 25″ centers) Floor kits: oak, aluminum, composite, combo Floor ratings up to 28,000 lb Multiple axle and aerodynamic configurations Scuff liners (wood, steel, aluminum, plastic) Tire monitoring / inflation systems Interior logistics (vertical & horizontal, bonded / riveted) Wide base tires Clarience Road Ready MCU Phillips REAR-VU™ camera MaxClearance® 110″ overhead door with EZ-Adjust® system Extended 7-Year wheel-end warranty |
